ConsoliBom extracts and consolidates the bill of materials from all your drawings. All that is left is to place the order.
ConsoliBom reads the tables on your drawings, groups articles worded differently from one drawing to the next, then nests the cutting across the whole job. One to three days of Excel work become minutes.
- What you drop off
- The job's drawings: GA drawings, isometrics, detail sheets. Vector PDFs or scans.
- What you get back
- A consolidated BOM, a cutting plan for the whole package, a purchase list.
- What you keep
- Control over the groupings, and the source drawing on every line.
From PDF drawings to delivered material, in five steps
One chain, from drop-off to purchase order. At every step a BOM line still knows which drawing and item number it came from.
Upload drawings
GA drawings, isometrics, detail sheets. Vector or scanned, all at once or as the job goes. Nothing to rename, nothing to sort.
BOM extraction
Title blocks and material take-off tables are read line by line: description, material, size, quantity, item number. On a scan, doubtful characters are flagged rather than guessed.
Semantic grouping
SEAMLESS PIPE 4", SCH.40 and PIPE 4IN SCH40 SMLS are the same pipe. ConsoliBom proposes one article; you confirm, split or merge.
Optimised cutting plan
1D for bars, profiles and tubes; 2D for plates. Real stock lengths, saw kerf counted, guillotine mode if the shop only runs a panel saw. It nests the consolidated BOM, so two different drawings can share the same bar.
Procurement tracking
The confirmed BOM becomes the purchase register. A supplier PO reconciles against it line by line: required, ordered, delivered, remaining, all in one place.
What it changes on a job
From raw drawings to a consolidated, checked BOM. Retyping goes away; the estimator only rules on the doubtful groups.
Nesting drawing by drawing wastes steel. Consolidating first lets cuts from different drawings share one bar and one plate.
Required, ordered, delivered and remaining live on the BOM itself. No more side spreadsheet to keep in sync by hand.
Sixty drawings, three ways to write the same pipe, one bar to order.
ConsoliBom sorts that out before you buy, without changing shop habits or the drawing formats you receive.
The source PDF is deleted from our servers after a successful extraction. Only the BOM lines remain, inside your job.
Each company sees only its own jobs, over fully encrypted traffic.
Data is stored and processed inside the EU, with no transfer outside the zone.
